Discover efficiency and versatility with our Terminal Pin Grooving Machine, an indispensable tool for the electric heater industry. This terminal pin end grinder is designed to perform two critical functions: the precise grinding of pin ends and the creation of the thread necessary for a secure connection. It is the ideal threader of pins for tubular heaters to guarantee that each terminal pin meets the highest standards of quality and performance. Its capacity to process terminal pins used as connection in tubular electric heaters makes it a strategic asset, improving the productivity and reliability of your products. This terminal pin grooving machine is synonymous with innovation and durability.
The ME-P03 Terminal Pin Grooving Machine is an advanced engineering solution designed for the high-precision processing of terminal pins used in tubular electric heaters. This specialized equipment takes care of grinding the pin ends and performing the machining of grooves/threads, guaranteeing optimal preparation for connection. It is a machine for grooving heater terminals that combines efficiency and accuracy, being fundamental for the creation of threads on terminal pins that ensure a robust and durable fixation. With this connection pin groover, manufacturers can ensure the quality and functionality of their components, optimizing the production process of heating heaters. Also known as a Terminal pin grooving machine, it is the perfect choice for the industry.
The Terminal Pin Grooving Machine is essential in processes where precision in the finishing of terminal pins is critical. Its main applications include:
Manufacture of Electric Heaters: Fundamental for the processing of terminal pins used as connection in tubular electric heaters, ensuring correct preparation for assembly.
Heating Element Industry: Used for the grinding of pin ends and the creation of threads on terminal pins in heating elements, guaranteeing the integrity of the connection.
Production of Specialized Fastening Elements: Applicable in the creation of grooves in connection pins that require a precise and secure fit.
Household Appliance and Automotive Sector: Where terminal pins must meet strict threading and finishing specifications to ensure the reliability of the final product.
Precision Metallurgy: For any small metal component requiring end grinding or the creation of fine threads.
This terminal pin grooving machine offers a series of advanced features and competitive advantages:
Dual Functionality: Efficiently combines the grinding of pin ends and the creation of threads on terminal pins, optimizing workflow.
High Precision: Guarantees a uniform and exact finish on each terminal pin, crucial for the quality and safety of electrical connections.
Wide Range of Diameters and Lengths: Compatible with applicable diameters from 1mm to 3.0mm and applicable terminal pin lengths from 30mm to 200mm, offering great flexibility in production.
Robust and Durable Construction: With a weight of 200kgs and dimensions of 900x700x800 mm, it ensures stability and a long service life in demanding industrial environments.
Optimal Power: Equipped with a power of 8000W, allowing for fast and efficient processing without compromising quality.
Customizable Voltage: Offers three-phase 380V 50Hz or 220V 50Hz options, with the possibility of customization, facilitating its integration into various electrical configurations.
Improved Connectivity: The creation of threads on terminal pins facilitates a safer assembly and reduces the possibility of failures in the connection.
|
Technical Characteristic |
Value |
|---|---|
|
Machine Type |
Terminal Pin Grooving Machine |
|
Voltage |
Three-Phase 380 V 50Hz; 220 V 50Hz (customizable) |
|
Power |
800 W |
|
Applicable Diameter |
1 mm ~ 3.0 mm |
|
Applicable Pin Length |
30 mm ~ 200 mm |
|
Dimensions (L x W x H) |
900 x 700 x 800 mm |
|
Weight |
200 kg |
|
Main Function |
Grind ends, groove, thread |
|
Terminal Material |
Steel (commonly) |
In an increasingly competitive industrial market, the choice of suitable machinery is a determining factor for success. Our Terminal Pin Grooving Machine is not just equipment; it is a strategic investment that boosts your visibility and profitability. When searching for solutions for machining grooves/threads or a terminal pin end grinder, industry professionals need equipment that guarantees maximum precision and efficiency. Our machine for grooving heater terminals meets these expectations, offering an impeccable finish on the terminal pins used as connection in tubular electric heaters.
This connection pin groover is designed to meet high-quality production demands, ensuring that each terminal pin is not only functional but also contributes to the durability and safety of the final product. The capacity of our threader of pins for tubular heaters to process a wide range of diameters and lengths makes it a versatile solution, adaptable to diverse manufacturing needs. By integrating this Terminal pin grooving machine into your production line, your company not only optimizes its internal processes but also improves its market positioning, attracting clients who seek excellence in every component of their electric heaters. Invest in technology that not only produces but also generates value and recognition.
Yes, our latest-generation automatic machine is designed based on the concept of rotary transfer or multi-stage processing. This allows for the integration of several processes in a single cycle:
Integrated Process: While one station performs the end grinding (grinding to remove burrs or for a tip finish), the next station can perform the grooving or thread rolling.
Competitive Advantage: Performing these functions in a single operation guarantees perfect concentricity between the tip and the thread, reducing human error and handling time between independent machines.
