This tube internal polisher is indispensable in industries requiring high-precision internal finishes and quality. Its main applications include:

• Automotive Industry:​ Internal polishing of engine components, injection systems, and hydraulic tubes to improve flow and durability.

• Precision Pipe Manufacturing:​ Honing of tubes and grinding of precision pipes for critical applications in sectors such as aerospace, medicine, and energy.

• Food and Pharmaceutical Industry:​ Internal wall cleaning and internal polishing of stainless steel tubes to comply with strict hygiene regulations and prevent residue accumulation.

• Hydraulic and Pneumatic Cylinder Manufacturing:​ Polishing of internal holes to reduce friction, improve sealing, and prolong component life.

• Chemical and Petrochemical Industry:​ Rust removal and surface finishing of straight tubes and ducts to optimize fluid transport and prevent corrosion.

• Armament Manufacturing:​ Deburring and internal polishing of barrels and high-precision components.

• Metallurgy and Special Steels:​ Treatment of special steels to improve their internal mechanical and aesthetic properties.

Main Features:

• Power and Precision:​ 4 Kw motor and 0.02 mm precision for a superior surface finish and controlled Ra roughness.

• Adjustable Speed:​ Regulation via frequency inverter for adjustable guide speed (0-12 m/min), adapting to different materials and internal polishing requirements.

• Tool Versatility:​ Compatible with abrasive belts, cloth/hemp wheels, drivers, and various arbor-mounted polishing heads for multiple operations such as deburring and tube honing.

• Compact and Robust Design:​ Dimensions of 1000x900x850 mm and 200 Kg weight, with a firm and stable structure for continuous operation.

• Integrated Environmental System:​ Includes a fan dust extraction system for efficient internal wall cleaning and a cleaner work environment.

• Adaptable Internal Diameter:​ Customizable processing internal diameter and length according to the material, with a 117 mm guide diameter.

Advantages:

• Superior Finish Quality:​ Achieves a high-quality surface finish, reducing Ra roughness and improving the aesthetics and functionality of straight tubes and precision pipes.

• Process Optimization:​ Allows for deburring, grinding, internal hole polishing, and rust removal on a single machine, simplifying the workflow.

• Increased Productivity:​ Adjustable speed and the possibility of automatic feeding (optional) increase efficiency and reduce cycle times.

• Material Versatility:​ Effective on stainless steel, special steels, and other metals, broadening its range of application.

• Cost Reduction:​ Minimizes the need for manual processes and improves the lifespan of polished components, generating long-term savings.

• Improved Work Environment:​ The dust extraction system contributes to a safer and cleaner environment.

The following table details the technical specifications of the Industrial Tube Internal Polishing Machine:

To maximize the adaptability and performance of the Tube Internal Polishing Machine to your specific needs, we offer various options and customization possibilities:

• Automatic Feeding:​ Integration of automatic feeding systems for high-volume processes, optimizing efficiency and reducing labor.

• PLC/CNC Controller:​ Implementation of an advanced PLC/CNC controller for full automation, programming of complex polishing cycles, and precise parameter monitoring, ideal for precision pipes.

• Specialized Polishing Tools:​ Supply of a wide range of abrasive belts, cloth/hemp wheels, drivers, and arbor-mounted polishing heads in different sizes and materials, optimized for the internal diameter and metal type (e.g., stainless steel, special steels).

• Ra Roughness Measurement Systems:​ Integration of sensors for online measurement of Ra roughness, ensuring real-time quality control of the surface finish.

• Adapters for Specific Internal Diameters:​ Development of tooling and adapters tailored for polishing internal holes with non-standard internal diameters or complex geometries.

• Additional Cooling Systems:​ Options for cooling systems for the arbor and polishing head in applications that generate excessive heat, protecting the material and the tool.

• Production Line Integration:​ Capability to integrate the polisher into existing production lines, facilitating a continuous workflow for tube honing and deburring.

• Custom Voltage and Frequency:​ Adaptation of the electrical system to the voltage and frequency standards of different regions or countries.

These options allow for configuring an internal polishing solution that perfectly fits operational and production requirements, guaranteeing an optimal surface finish and exceptional internal wall cleaning on every piece.
