Heat-Resistant Pressure Sensitive Adhesive Tape (For Heat Tracing Fixation)

Heat-Resistant Pressure Sensitive Adhesive Tape (For Heat Tracing Fixation)

Heat-resistant pressure sensitive adhesive tape, using high-strength glass fiber tape as the substrate and coated with a special high-performance adhesive. It is a reliable helper for the installation and fixation in Heat Tracing​ systems, ensuring the heating cable is adhered firmly and lastingly.

Contact Us

This product is specifically designed for Heat Tracing​ systems. It is a high-temperature resistant pressure-sensitive fixing tape, manufactured from glass fiber tape coated with a special adhesive. It offers excellent heat resistance and bonding strength, used to securely fix the heating cable after installation, ensuring the system's long-term stable operation.

In Heat Tracing​ systems, used for fixing the heating cable on pipes.

  • Excellent Heat Resistance:​ Can withstand the operating temperature of the Heat Tracing​ system and relatively high ambient temperatures, with stable performance.

  • Strong Fixing Force:​ The special adhesive provides high initial tack and lasting adhesion, capable of firmly fixing the heating cable on various pipe surfaces, preventing detachment.

  • High-Strength Substrate:​ The glass fiber tape substrate features characteristics such as tensile resistance, moisture resistance, and chemical resistance, making it robust and durable.

  • Convenient Construction:​ Pressure-sensitive adhesion, easy to use, requires no complex tools.

  • Product Name:​ Heat-Resistant Pressure Sensitive Adhesive Tape (Fixing Tape for Heat Tracing)

  • Substrate:​ Glass fiber tape

  • Adhesive:​ Heat-resistant pressure sensitive adhesive

  • Recommended Fixing Interval:​ Fix transversely along the pipe approximately every 300mm.

  • Color:​ Typically white or black (can be customized according to demand).

  • Common Specifications:

    • Width: 19mm, 25mm, etc.

    • Length: 20 meters/roll, 33 meters/roll, 50 meters/roll, etc. (Supplied length depends on the actual heated pipeline length requirements).

  • Operating Temperature Range:​ Can continuously withstand maximum temperatures of approximately 120°C to 150°C (depends on the specific adhesive model, consultation for confirmation is recommended).

  • Specification Customization:​ Different widths and lengths (roll length) can be customized according to customer requirements.

  • Color Customization:​ Specific colors can be provided to suit on-site identification or aesthetic requirements.

  • Performance Customization:​ The adhesive formula can be evaluated and adjusted for special environments (e.g., higher/lower temperatures, specific chemical environments).

FAQ

This heat-resistant pressure sensitive adhesive tape is specifically designed for Heat Tracing​ environments. It can generally continuously withstand maximum temperatures of approximately 120°C to 150°C. The specific maximum temperature resistance should be determined based on the selected adhesive model. When selecting the type, ensure its temperature resistance range is higher than your heat tracing system's maximum operating temperature and the ambient temperature.
